High Performance Pick and Hold Solenoid Driver Module is designed to avoid over heating of the solenoid coil once it is energized. It is done by applying an initial higher voltage to the solenoid coil to provide the
necessary force (torque) to pull the plunger in. Then, when seated, drops the voltage down to a level sufficient enough to maintain the plunger in the seated position.
The pick time and hold voltage are variable and set using the onboard potentiometers.
This module is capable of driving two devices independently.
This product is RoHS complaint.
Pulse, 3-50 VDC
Equal to Power Supply Voltage
Variable, Set by a Trim Pot, 0 to 2,000 mS
Variable, Set by a Trim Pot, 0 to 100% of supply voltage
